Engineered for success
Maximise your AI PC productivity by seamlessly using Gen AI tools across up to four 4K 60Hz displays, staying powered with up to 130W power delivery, and connecting all your peripherals effortlessly.
More manageable and secure
Elevate the IT management experience by directly managing your smart docks from the Dell Device Management Console - no PC connection or software required.
More manageable
Reduce IT efforts by scheduling updates during off-hours, while ensuring fleetwide firmware compliance and eliminating end user interruptions.
Effortless maintenance
Remotely configure, deploy and update smart docks over Wi-Fi via a holistic peripheral management solution.
Unlock out-of-band management on select Intel vPro® PCs with Intel® Active Management Technology (Intel® AMT) over Thunderbolt via the connected dock.
Work securely
Keep users working confidently with enterprise-grade WPA-3 192-bit encryption for secure Wi-Fi communication. Safeguard your sensitive data with tamper-resistant, hardware-based encryption built into your Dell Pro Thunderbolt 4 Smart Dock.
Connect your way
Configure your workspace to your liking with an ambidextrous USB-C cable[1] that can be routed left or right.
Designed for sustainability
The Dell Pro Thunderbolt 4 Smart Dock is built with post-consumer recycled materials with recycled or renewable packaging.
- General Information
- Manufacturer
- Dell Technologies
- Manufacturer Website Address
- http://www.dell.com.au
- Brand Name
- Dell
- Product Series
- Pro
- Product Type
- Docking Station
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Connectivity Technology
- Wired
- Device Supported
- Notebook
- Desktop PC
- Features
- Power Delivery Pass-through
- Management Features
- MAC Address Pass-through
- PXE Boot
- Dock Power Button Sync
- Wake-on-LAN
- Kernel Direct Memory Access (DMA) Protection
- Intel AMT over Thunderbolt with select Intel vPro PCs
- Port Disablement
- WLAN to LAN Switch
- Number of Displays Supported
- 4
- Screen Mode Supported
- 4K @ 60Hz
- 6K @ 60Hz
- 8K @ 60Hz
- QHD @ 60Hz
- WQHD @ 60Hz
- 5K @ 60Hz
- WUHD
- Supported Resolutions
- 3840 x 2160
- 6144 x 3456
- 7680 x 4320
- 2560 x 1440
- 3440 x 1440
- 5120 x 2160
- Maximum Data Transfer Rate
- 1.25 GB/s
- Security Slot Type
- Kensington Security Slot
- Power Delivery
- 130W (Dell Systems)
- 96W (non-Dell Systems)
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- Interfaces/Ports
- Host Interface
- Thunderbolt 4
- Total Number of USB Ports
- 6
- Number of USB 3.2 Gen 2 Type-A Ports
- 4
- Number of USB Type-A Ports
- 4
- Number of USB Type-C Ports
- 2
- USB Type-A
- Yes
- USB Type-C
- Yes
- USB Type-C Detail
- 1 x USB-C 3.2 Gen 2 Multi-function DisplayPort 1.4, 1 x USB-C 3.2 Gen 2 (10 Gbps)
- Network (RJ-45)
- Yes
- Number of DisplayPorts
- 2
- DisplayPort
- Yes
- DisplayPort Version
- 1.4
- Number of HDMI Ports
- 1
- HDMI
- Yes
- HDMI Version
- 2.1
- Thunderbolt
- Yes
- Thunderbolt Ports Quantity
- 2
- Number of Thunderbolt 4 Ports
- 2
- Software
- Operating System Supported
- Windows 10
- Windows 11
- Ubuntu
- Red Hat Enterprise Linux
- ChromeOS
- macOS
- Power Description
- Maximum Power Supply Wattage
- 180 W
- Power Source Type
- Power Adapter
- Physical Characteristics
- Height
- 205 mm
- Width
- 90 mm
- Depth
- 35.3 mm
- Weight (Approximate)
- 579 g
- Miscellaneous
- Package Contents
- Pro Thunderbolt 4 Smart Dock - SD25TB4
- Power Adapter and Power Cord
- Documentation (Quick Start Guide, Safety, Environmental, and Regulatory Information)
- Kensington Security Slot
- Yes
